CX2033 | Basic CPU module
Embedded PCs from the CX2000 product family
CX20x3 - Embedded PCs with AMD-Ryzen™ CPU and up to four cores
The CX2033 is a modularly expandable Embedded PC for DIN rail mounting and has an AMD Ryzen™ V1202B CPU with a clock speed of 2.3 GHz and two cores. The power supply unit required for operation enables the direct use and connection of all Beckhoff I/O components to this CPU module.
The TwinCAT automation software turns the CX2033 system into a high-performance PLC and motion control system that can be used with or without visualization. Both TwinCAT 2 in 32-bit mode and the latest TwinCAT 3 version in 64-bit mode are supported. Continuing support for TwinCAT 2 by the CX2033 and CX2043 guarantees investment protection for projects and systems that were or will be created with this 32-bit generation.
The devices from the CX20x3 series are characterized by outstanding real-time characteristics under the highest computing loads. This enables deterministic processing with short cycle times on the individual cores of the CPUs.
The basic equipment of the hardware includes two independent Gbit-Ethernet interfaces, four USB 3.0 Gen. 2 ports, one DVI-D interface, and a multi-option interface that can be equipped ex factory with a flexible choice of further interfaces (e.g., serial port, fieldbus, or second video connection).
The internal RAM size is 8 GB; up to 16 GB are also optionally possible. The controller boots from the CFast card and has an internal 128 kB NOVRAM for use as a persistent data memory.
The CX2033 is fanless and has no rotating components. Cooling takes place by passive thermal convection.
Other components from the CX2000 family can be connected via the multi-pin terminals on either side. Up to four modules of the type CX2500-xxxx can be connected on the left side of the basic CPU module. The connection order is irrelevant. Internally, the modules are connected via PCI Express and can be plugged to the CPU in the field.
Modules of the type CX2550 (e.g., hard disks/SSD modules) and a power supply unit of the type CX2100-xxxx can be connected on the right. The power supply unit supplies power to the entire system of CPU module and all plugged optional components. All Beckhoff EL and KL terminals can be connected directly to the power supply unit. A compact unit comprising controller and I/O level is thus created on the DIN rail.
The extended operating temperature range from -25 °C to +60 °C enables the CX2033 to be used under climatically challenging conditions.
|Processor||AMD Ryzen™ V1202B 2.3 GHz|
|Number of cores||2|
|Flash memory||slot for CFast card, card not included|
|Main memory||8 GB DDR4 RAM (expandable ex factory to 16 GB)|
|Persistent memory||128 kB NOVRAM integrated|
|Interfaces||2 x RJ45 10/100/1000 Mbit/s, 1 x DVI-D, 4 x USB 3.0, 1 x optional interface|
|Cooling||passive cooling, optionally with active cooling ex factory|
|Diagnostics LED||1 x power, 1 x TC status, 1 x flash access, 2 x bus status|
|Clock||internal battery-backed clock for time and date (battery exchangeable)|
|Operating system||Windows 10 IoT Enterprise 2019 LTSC, Windows 10 IoT Enterprise 2021 LTSC, TwinCAT/BSD|
|Control software||TwinCAT 2 runtime|
TwinCAT 3 runtime (XAR)
|I/O connection||via power supply module (E-bus or K-bus, automatic recognition)|
|Power supply||24 V DC (-15 %/+20 %)|
|Max. power consumption||42 W|
|Dimensions (W x H x D)||144 mm x 99 mm x 91 mm|
|Weight||approx. 1165 g|
|Relative humidity||95 %, no condensation|
|Operating/storage temperature||-25…+60 °C/-40…+85 °C|
|EMC immunity/emission||conforms to EN 61000-6-2/EN 61000-6-4|
|Vibration/shock resistance||conforms to EN 60068-2-6/EN 60068-2-27|
|TwinCAT 3 platform level||Performance Plus (50); please see here for an overview of all the TwinCAT 3 platform level|
|CX2033-0100||CPU module, no operating system, no TwinCAT|
|CX2033-0160||CPU module, Microsoft Windows 10 IoT Enterprise 2019 LTSC, 32 bit, no TwinCAT|
|CX2033-0161||CPU module, Microsoft Windows 10 IoT Enterprise 2019 LTSC, 32 bit, TwinCAT 2 PLC runtime|
|CX2033-0162||CPU module, Microsoft Windows 10 IoT Enterprise 2019 LTSC, 32 bit, TwinCAT 2 NC PTP runtime|
|CX2033-0163||CPU module, Microsoft Windows 10 IoT Enterprise 2019 LTSC, 32 bit, TwinCAT 2 NC I runtime|
|CX2033-0170||CPU module, Microsoft Windows 10 IoT Enterprise 2019 LTSC, 64 bit, no TwinCAT|
|CX2033-0175||CPU module, Microsoft Windows 10 IoT Enterprise 2019 LTSC, 64 bit, TwinCAT 3 runtime (XAR), no licenses included|
|CX2033-0185||CPU module, TwinCAT/BSD, TwinCAT 3 runtime (XAR), no licenses included|
|CX2033-0190||CPU module, Microsoft Windows 10 IoT Enterprise 2021 LTSC, 64 bit, no TwinCAT|
|CX2033-0195||CPU module, Microsoft Windows 10 IoT Enterprise 2021 LTSC, 64 bit, TwinCAT 3 runtime (XAR), no licenses included|
CX20x3-016x: only 4 GB RAM can be used with Windows 10 IoT Enterprise 2019 LTSC 32 Bit
TwinCAT/BSD requires a CFast flash card with a minimum capacity of 20 GB
Windows 10 IoT Enterprise requires a CFast flash card with a minimum capacity of 40 GB.
TwinCAT 3 runtime (XAR) is preinstalled, without licenses. Please order TwinCAT 3 licenses separately from the TwinCAT 3 Price List.
|CX2900-0010||Operating system preequipped on 2½-inch HDD/SSD for CX20x0, CX20x2 and CX20x3.
Requires the extension module CX2550-0020 and one 2½-inch HDD/SSD.
|CX2900-0301||“Active cooling”: factory conversion of the CX2033 CPU module for active cooling in order to enable flexible
installation positions (see documentation). Active cooling takes place via a fan cartridge. This option requires the use of a power supply unit type CX2100-0014 or CX2100-0914.
|CX2900-0305||Memory extension to 16 GB DDR4 RAM, instead of 8 GB DDR4 RAM for CX2033 and CX2043. For the CX2033 this extension reduces the maximum permissible ambient temperature to 50 °C. For operation of the CX2033 up to 60 °C the active cooling CX2900-0301 is required.|
|CX2033-N010||DVI-D interface, additional DVI-D port for clone or extended display mode.
Is not supported by TwinCAT/BSD.
|CX2033-N011||DisplayPort interface, additional DisplayPort for clone or extended display mode.
Is not supported by TwinCAT/BSD.
|CX2033-N030||RS232 interface, D-sub plug, 9-pin|
|CX2033-N031||RS485 interface, D-sub socket, 9-pin, configuration as an end point, without echo, termination on|
|CX2033-N031-0001||RS485 interface, D-sub socket, 9-pin, configuration as an end point, with echo, termination on|
|CX2033-N031-0002||RS485 interface, D-sub socket, 9-pin, configuration as drop point, without echo, termination off|
|CX2033-N031-0003||RS485 interface, D-sub socket, 9-pin, configuration as drop point, with echo, termination off|
|CX2033-N031-0004||RS422 interface, D-sub socket, 9-pin, configuration as full duplex end point, termination on|
|CX2033-M112||2 x EtherCAT master interface|
|CX2033-B110||EtherCAT slave interface, EtherCAT IN and OUT (2 x RJ45)|
|CX2033-M310||PROFIBUS master interface, D-sub socket, 9-pin|
|CX2033-B310||PROFIBUS slave interface, D-sub socket, 9-pin|
|CX2033-M510||CANopen master interface, D-sub plug, 9-pin|
|CX2033-B510||CANopen slave interface, D-sub plug, 9-pin|
|CX2033-M930||PROFINET RT, controller interface, Ethernet (2 x RJ45 switch)|
|CX2033-B930||PROFINET RT, device interface, Ethernet (2 x RJ45 switched)|
|CX2900-0038||40 GB CFast card, 3D flash, extended temperature range|
|CX2900-0040||80 GB CFast card, 3D flash, extended temperature range|
|CX2900-0042||160 GB CFast card, 3D flash, extended temperature range|
|CX2900-0044||320 GB CFast card, 3D flash, extended temperature range|
|CX2900-0101||Housing locking clips (black) for the CX52x0, CX56x0 and CX20xx series
10 locking pin sets (each set consisting of two pieces)
|CX2900-0102||Cover for left-side module bus connector, 5 pieces|
|CX2900-0103||Spare fan cartridge for CX2040, CX2042, CX2043, CX2062, CX2072 and CX2020, CX2030, CX2033 with fan option
– cartridge consisting of chassis and 60 mm fan
– simple exchange in the field due to wireless installation
– dimensions (W x H x D) 67 x 62 x 16 mm
|CX1900-0102||Spare battery suitable for CX10x0, CX81x0, CX5xxx, CX90x0, CX20xx
– lithium button cell type CR2032, 3V/225 mAh
– follow polarity when installing
